Jonard MOS-2428
Tools · DIP/IC Insertion Tool (24-28 Pins)
Specs come from the parts catalog. Wiring diagram
Documents & links
| insertion-tools-insertion-tool?v=326 | insertion-tools-insertion-tool?v=326 |
Outbound links only. HireLV does not host these files.
Reviews
Be the first to review this.
Sign in to write a review.
Add to my tools
Sign in to add this to your tools.
Specs
| Function | Insertion |
|---|---|
| Chip Package Type | DIP |
| Pin Count | 24-28 |
| Pitch | 0.60" (15.24 mm) |
| Dimensions | 4.6 in x 1.4 in x 0.8 in (11.68 cm x 3.56 cm x 2.03 cm) |
| Weight | 0.1 lb (45.4 g) |
